2007 Harley Davidson Flstn Softail Deluxe

2007 Harley Davidson Flstn Softail Deluxe

Harley Davidson FLSTN Softail Deluxe

Make Model

Harley Davidson FLSTN Softail Deluxe

Year

2007 - 08

Engine

Four stroke, 45� V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder

Capacity

1584 cc / 96 cu-in
Bore x Stroke 95.2 x 111.2 mm
Cooling System Air cooled
Compression Ratio 9.2:1

Induction

Electronic Sequential Port Fuel Injection (ESPFI)

Ignition

Single-fire, non-wasted, map-controlled spark ignition
Starring Electric

Max Torque

124.7 Nm / 92 ft. lbs @ 3000 rpm

Transmission

6 Speed
Final Drive Belt
Gear Ratio 1st 9.311  2nd 6.454  3rd 4.793  4th 3.882  5th 3.307  6th 2.79
Frame Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded

Front Suspension

41.3 mm telescopic, chrome dust covers

Rear Suspension

Hidden, horizontal-mounted, coil-over shock

Front Brakes

Single 292mm disc 4 piston caliper

Rear Brakes

Single 292mm disc 4 piston caliper

Front Tyre

D402F MT90-16

Rear Tyre

D402 MU85B16
Rake 32�
Fork Angle 32�
Trail 147.3 mm / 5.8 in
Dimensions Length 2405.4 mm / 94.7 in
Wheelbase 1638 mm / 64.5 in
Seat Height Laden2    622 mm  /  24.5 in.
Unladen  673 mm  /  26.5 in.
Gross Vehicle Weight Rating 526.0 kg  /  1160 lb
Ground Clearance 122 mm / 4.8 in
Dry Weight 315 kg / 693 lbs.

Wet Weight

329.0 kg  /  726 lb

Fuel Capacity

18.9 Litres / 5.0 gal

FLSTN Softail� Deluxe Model Overview
FLSTN Softail Deluxe sets its sights to the future with a look to the past. A 24.5-inch seat height makes this the lowest Harley-Davidson 2007 model and one of the lowest on the market. The Softail Deluxe is heavy on nostalgic style as a unique paint scheme, beautiful cloisonn� and abundant chrome combine with the new Twin Cam 96B engine, 6-speed Cruise Drive transmission and Electronic Sequential Port Fuel Injection (ESPFI) for stunning overall performance. The Softail Deluxe offers premium rider comfort with a comfortable pullback riser and wide handlebar. An integrated luggage rack, checked seat side panels with a chrome grab rail, new full-length footboards, wide whitewall tires on Chrome, Laced Steel wheels, special tank and fender emblems and a classic tombstone tail light evoke the past. New four-hole fender supports allow additional customizing creativity. Chrome, Profile Laced Aluminum wheels are available as a factory-installed option. Available in four solid and three new tone-tone color options.

Rigid-mount 1584cc Twin Cam 96B balanced engine
Black powder-coated engine with chrome covers
New 6-speed Cruise Drive transmission
Electronic Sequential Port Fuel Injection (ESPFI) standard
Hard tail styling with hidden, horizontal rear shocks
Low 24.5-inch seat height
Integrated luggage rack
Wide whitewall tires and Chrome, Laced Steel 16-inch wheels
Chrome oil tank
Chrome shotgun exhaust
Pullback risers and handlebar
Tombstone tail light
Distinctive headlight nacelle
Clear-lens reflector-optic passing lamps
Easily removable passenger pillion
Full-length floorboards with heel/toe shift lever
Easy-reach sidestand
